FCC ID A4R-GJQ8U

Google GJQ8U FCC filing (A4R-GJQ8U)

Public FCC record for Google GJQ8U (A4R-GJQ8U), a digital transmission system device filed by Google LLC. Public exhibits include external photos, internal photos, a user manual, and RF exposure information. Radio evidence covers 6 GHz Wi-Fi, 5 GHz Wi-Fi, and 2.4 GHz Wi-Fi / Bluetooth.

Smart HomeA4R brand hub
Google LLC
A4R-GJQ8U
Smart Home
Jun 17, 2024
Plain-English filing summary

What this FCC record tells you

GJQ8U is the device filed under FCC ID A4R-GJQ8U by Google LLC.

Public exhibits include internal and external photos, a user manual, RF exposure information, and wireless test reports.

Those exhibits help verify what the device looks like, how its radios were tested, and setup or use details from the manual.

The listed radio coverage includes 6 GHz Wi-Fi, 5 GHz Wi-Fi, and 2.4 GHz Wi-Fi / Bluetooth.

Terms in this filing

FCC ID
A public identifier assigned to a wireless device authorization.
Grantee Code
The manufacturer/applicant portion of an FCC ID.
DTS
FCC equipment class for digital transmission systems.
Part 15C
FCC rules for many unlicensed intentional radiators.
Part 15E
FCC rules often associated with 5 GHz and 6 GHz network devices.
Official FCC facts

FCC filing details

Raw application fields from the FCC record, shown separately from the plain-English summary.

Grantee codeA4RThe FCC-assigned applicant code at the start of the FCC ID.
Product code-GJQ8UThe filing-specific product code. It is not always the retail product name.
Application purposeOriginal EquipmentShows whether the FCC action was an original authorization, change, or related filing update.
FCC equipment classDTS - digital wireless transmitterIn plain English, this covers wireless data transmitters such as Wi-Fi or Bluetooth-style radios.
FCC rule partsPart 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rules; Part 15.255Part 15C is the FCC rule bucket used for many low-power Wi-Fi, Bluetooth, and similar transmitters. Part 15E is commonly used for 5 GHz and 6 GHz Wi-Fi or network radios. Part 15.255 is one of the FCC rule sections cited for this authorization.
Application IDy3+xgzd5prDp5haA3n3R9Q==The FCC tracking ID for this application batch.
Filing timeline

What changed in this filing

A quick read on what each public FCC application changed or confirmed, with source links attached.

Jun 17, 2024

Original Equipment

3 FCC applications

3 related FCC applications share this date and purpose, so they are grouped here instead of repeated as separate Original Equipment rows.

  • Applications: y3+xgzd5prDp5haA3n3R9Q==, Cp7hkzBmo1XPNRObbxrE3g==, az+voXmOMhd/rpJqp7e0mw==
  • Equipment classes: DTS - digital wireless transmitter; NII - Wi-Fi-style wireless device
  • FCC rules: Part 15.255; Part 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rules
  • Bands: 6 GHz Wi-Fi: 1 range; 5 GHz Wi-Fi: 4 ranges; 2.4 GHz Wi-Fi / Bluetooth: 2 ranges
  • Public exhibits: user manual, external photos, internal photos, RF exposure, RF test report
SourcesFCC grantFCC exhibit listUser manual
Wireless test details

Wireless details from FCC tests

This section summarizes what the FCC test documents say about the device's wireless connections and tested frequency ranges. RF exposure or SAR rows are compliance/safety context, not a speed or range claim.

This filing covers Wi-Fi-style wireless operation, including the shared frequency ranges shown below.

FCC equipment classDTS - digital wireless transmitterThe FCC shorthand for the radio behavior reviewed in this filing.
FCC rule partsPart 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rules; Part 15.255The rule sections cited by the grant or test documents.
Frequency bands6 GHz Wi-Fi: 1 range; 5 GHz Wi-Fi: 4 ranges; 2.4 GHz Wi-Fi / Bluetooth: 2 rangesThe radio ranges the FCC filing lists for the device.Source: FCC grant; 7 ranges grouped below
Power density0.04 mW/cm2RF exposure/SAR values are FCC compliance checks for radio energy near people, not product performance specs.Source: RF Exposure Info p. 10
Public photo exhibits

Public FCC photos

Product photos from public FCC exhibits, formatted for easier browsing. External photos show the enclosure and labels; internal photos show boards, antennas, and other compliance-relevant hardware.

Google GJQ8U external FCC photo from External Photos p. 2
External viewGoogle GJQ8U external FCC photo from External Photos p. 2Source: External Photos p. 2
Google GJQ8U external FCC photo from External Photos p. 2
External viewGoogle GJQ8U external FCC photo from External Photos p. 2Source: External Photos p. 2
Google GJQ8U external FCC photo from External Photos p. 3
External viewGoogle GJQ8U external FCC photo from External Photos p. 3Source: External Photos p. 3
Google GJQ8U external FCC photo from External Photos p. 3
External viewGoogle GJQ8U external FCC photo from External Photos p. 3Source: External Photos p. 3
Google GJQ8U external FCC photo from External Photos p. 4
External viewGoogle GJQ8U external FCC photo from External Photos p. 4Source: External Photos p. 4
Google GJQ8U external FCC photo from External Photos p. 4
External viewGoogle GJQ8U external FCC photo from External Photos p. 4Source: External Photos p. 4
Google GJQ8U external FCC photo from External Photos p. 5
External viewGoogle GJQ8U external FCC photo from External Photos p. 5Source: External Photos p. 5
Google GJQ8U internal FCC photo from Internal Photos p. 2
Internal viewGoogle GJQ8U internal FCC photo from Internal Photos p. 2Source: Internal Photos p. 2
User manual

User manual

The FCC filing includes a public user manual source.

Official FCC source: Users Manual (6968852)694 KB public file
  • Official manual source

    The FCC filing includes a public manual source. The available text is mostly regulatory, safety, or compliance information, so this page links the official file instead of presenting it as setup guidance.

    Source: Users Manual (6968852)
Open FCC filing source

Official FCC documents

Open the original FCC files used to check the details shown here. Badges separate whether a file is public from whether details from that file appear on this page.

FCC grant

Official FCC grant or authorization record.

Public FCC fileUsed on this page
Source

Users Manual (6968852)

Public user manual or setup guide from the FCC filing.

Public FCC fileOriginal FCC file
FCC type: Users ManualApplication ID: y3+xgzd5prDp5haA3n3R9Q==
Source

Internal Photos (6968849)

Internal product photo exhibit from the FCC filing.

Public FCC fileUsed on this page
FCC type: Internal PhotosApplication ID: y3+xgzd5prDp5haA3n3R9Q==
Source

External Photos (6968848)

External product photo exhibit from the FCC filing.

Public FCC fileUsed on this page
FCC type: External PhotosApplication ID: y3+xgzd5prDp5haA3n3R9Q==
Source

RF Exposure Info (7166117)

RF exposure exhibit from the FCC filing.

Public FCC fileUsed on this page
FCC type: RF Exposure InfoApplication ID: y3+xgzd5prDp5haA3n3R9Q==
Source

44 additional official FCC documents

Additional FCC exhibits are grouped here by source type instead of repeated as individual rows.

Source index
1 grant record2 manuals or setup guides2 internal photo exhibits2 external photo exhibits2 RF exposure exhibits11 RF report exhibits24 test report exhibits
