FCC ID SWX-U7PROXS

Ubiquiti U7PROXS access point FCC filing (SWX-U7PROXS)

Public FCC record for Ubiquiti U7PROXS (SWX-U7PROXS), a digital transmission system device filed by Ubiquiti Inc. Public exhibits include external photos, internal photos, a user manual, and RF exposure information. Radio evidence covers 6 GHz Wi-Fi, 5 GHz Wi-Fi, and 2.4 GHz Wi-Fi / Bluetooth.

NetworkingSWX brand hub
Ubiquiti Inc.
SWX-U7PROXS
Networking
Mar 7, 2025
Plain-English filing summary

What this FCC record tells you

U7PROXS is the device filed under FCC ID SWX-U7PROXS by Ubiquiti Inc.

Public exhibits include internal and external photos, a user manual, RF exposure information, and wireless test reports.

Those exhibits help verify what the device looks like, how its radios were tested, and setup or use details from the manual.

The listed radio coverage includes 6 GHz Wi-Fi, 5 GHz Wi-Fi, and 2.4 GHz Wi-Fi / Bluetooth.

Terms in this filing

FCC ID
A public identifier assigned to a wireless device authorization.
Grantee Code
The manufacturer/applicant portion of an FCC ID.
DTS
FCC equipment class for digital transmission systems.
Part 15C
FCC rules for many unlicensed intentional radiators.
Part 15E
FCC rules often associated with 5 GHz and 6 GHz network devices.
Official FCC facts

FCC filing details

Raw application fields from the FCC record, shown separately from the plain-English summary.

Grantee codeSWXThe FCC-assigned applicant code at the start of the FCC ID.
Product code-U7PROXSThe filing-specific product code. It is not always the retail product name.
Application purposeOriginal EquipmentShows whether the FCC action was an original authorization, change, or related filing update.
FCC equipment classDTS - digital wireless transmitterIn plain English, this covers wireless data transmitters such as Wi-Fi or Bluetooth-style radios.
FCC rule partsPart 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rulesPart 15C is the FCC rule bucket used for many low-power Wi-Fi, Bluetooth, and similar transmitters. Part 15E is commonly used for 5 GHz and 6 GHz Wi-Fi or network radios.
Application IDW83JB4loaF4EWaIRkwkKZg==The FCC tracking ID for this application batch.
Filing timeline

What changed in this filing

A quick read on what each public FCC application changed or confirmed, with source links attached.

Mar 7, 2025

Original Equipment

4 FCC applications

4 related FCC applications share this date and purpose, so they are grouped here instead of repeated as separate Original Equipment rows.

  • Applications: qfV6xlv9xpL6J2ccx5O5yQ==, MQebfsTIveA/OToAwi8Q9w==, 33+mZj3FO+qNA21466wgaw==, W83JB4loaF4EWaIRkwkKZg==
  • Equipment classes: 15E - 6 GHz Subordinate Indoor Device; 15E - 6 GHz Low Power Indoor Access Point; NII - Wi-Fi-style wireless device; DTS - digital wireless transmitter
  • FCC rules: Part 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rules
  • Bands: 6 GHz Wi-Fi: 1 range; 5 GHz Wi-Fi: 4 ranges; 2.4 GHz Wi-Fi / Bluetooth: 1 range
  • Public exhibits: user manual, external photos, internal photos, RF exposure, RF test report
SourcesFCC grantFCC exhibit listUser manual
Wireless test details

Wireless details from FCC tests

This section summarizes what the FCC test documents say about the device's wireless connections and tested frequency ranges. RF exposure or SAR rows are compliance/safety context, not a speed or range claim.

This filing covers Wi-Fi-style wireless operation, including the shared frequency ranges shown below.

FCC equipment classDTS - digital wireless transmitterThe FCC shorthand for the radio behavior reviewed in this filing.
FCC rule partsPart 15C - low-power wireless rules; Part 15E - 5 GHz / 6 GHz wireless rulesThe rule sections cited by the grant or test documents.
Frequency bands6 GHz Wi-Fi: 1 range; 5 GHz Wi-Fi: 4 ranges; 2.4 GHz Wi-Fi / Bluetooth: 1 rangeThe radio ranges the FCC filing lists for the device.Source: FCC grant; 6 ranges grouped below
Power density1 mW/cm2RF exposure/SAR values are FCC compliance checks for radio energy near people, not product performance specs.Source: RF Exposure Info p. 1
Public photo exhibits

Public FCC photos

Product photos from public FCC exhibits, formatted for easier browsing. External photos show the enclosure and labels; internal photos show boards, antennas, and other compliance-relevant hardware.

Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 1
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 1Source: Internal Photos p. 1
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 2
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 2Source: Internal Photos p. 2
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 1
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 1Source: Internal Photos p. 1
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 2
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 2Source: Internal Photos p. 2
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 3
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 3Source: Internal Photos p. 3
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 4
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 4Source: Internal Photos p. 4
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 5
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 5Source: Internal Photos p. 5
Ubiquiti U7PROXS internal FCC photo from Internal Photos p. 6
Internal viewUbiquiti U7PROXS internal FCC photo from Internal Photos p. 6Source: Internal Photos p. 6
Manual notes

Manual notes

Useful setup, control, or operating details from the public FCC manual exhibit.

Official FCC source: Users Manual (8102888)3 pages266 KB public file

  • • The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet in the 5.925-6.425 GHz band.

    Source: Users Manual (8102888), page 2

  • • Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or

    Source: Users Manual (8102888), page 2
  • RF Exposure Warning

    The antennas used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter.

    Source: Users Manual (8102888), page 3
Open FCC filing source

Official FCC documents

Open the original FCC files used to check the details shown here. Badges separate whether a file is public from whether details from that file appear on this page.

FCC grant

Official FCC grant or authorization record.

Public FCC fileUsed on this page
Source

Users Manual (8102888)

Public user manual or setup guide from the FCC filing.

Public FCC fileUsed on this page
FCC type: Users ManualApplication ID: W83JB4loaF4EWaIRkwkKZg==
Source

Internal Photos (8102885)

Internal product photo exhibit from the FCC filing.

Public FCC fileUsed on this page
FCC type: Internal PhotosApplication ID: W83JB4loaF4EWaIRkwkKZg==
Source

External Photos (8102887)

External product photo exhibit from the FCC filing.

Public FCC fileOriginal FCC file
FCC type: External PhotosApplication ID: W83JB4loaF4EWaIRkwkKZg==
Source

RF Exposure Info (8102891)

RF exposure exhibit from the FCC filing.

Public FCC fileUsed on this page
FCC type: RF Exposure InfoApplication ID: W83JB4loaF4EWaIRkwkKZg==
Source

87 additional official FCC documents

Additional FCC exhibits are grouped here by source type instead of repeated as individual rows.

Source index
1 grant record7 manuals or setup guides7 internal photo exhibits3 external photo exhibits3 RF exposure exhibits28 RF report exhibits38 test report exhibits
