Public FCC record for Ubiquiti AF-11FX-H (SWX-AF11FX), a digital transmission system device filed by Ubiquiti Inc. Public exhibits include external photos, internal photos, a user manual, and wireless test details. Radio evidence covers 6 GHz Wi-Fi.
AF-11FX-H is the device filed under FCC ID SWX-AF11FX by Ubiquiti Inc.
Public exhibits include internal and external photos, a user manual, and wireless test reports.
The strongest extracted details are internal and external photos and manual excerpts.
Those exhibits help verify what the device looks like, how its radios were tested, and setup or use details from the manual.
The listed radio coverage includes 6 GHz Wi-Fi.
Manual excerpts cover button controls, status lights, and setup.
Raw application fields from the FCC record, shown separately from the plain-English summary.
A quick read on what each public FCC application changed or confirmed, with source links attached.
This FCC application appears to be the original authorization package for the device, with the matching grant and public exhibits grouped together.
This section summarizes what the FCC test documents say about the device's wireless connections and tested frequency ranges. RF exposure or SAR rows are compliance/safety context, not a speed or range claim.
This filing covers Wi-Fi-style wireless operation, including the shared frequency ranges shown below.
| FCC equipment class | DTS - digital wireless transmitterThe FCC shorthand for the radio behavior reviewed in this filing. |
|---|---|
| FCC rule parts | Part 101The rule sections cited by the grant or test documents. |
| Frequency bands | 6 GHz Wi-Fi: 6 rangesThe radio ranges the FCC filing lists for the device.Source: FCC grant; 6 ranges grouped below |
| Frequency range | 10.7 - 11.7 GHzSource: Test Report (3152229) p. 12 |
| Bandwidth | 3.75 MHz | 5.00 MHz | 10.00 MHz | 30.00 MHz | 40.00 MHzSource: Test Report (3152229) p. 26; Test Report (3152229) p. 27; Test Report (3152229) p. 28; Test Report (3152229) p. 29; Test Report (3152229) p. 30 |
Product photos from public FCC exhibits, formatted for easier browsing. External photos show the enclosure and labels; internal photos show boards, antennas, and other compliance-relevant hardware.
Setup, reset, and status notes from the public manual. Use the official source document for full instructions and safety context.
Batch-approved public quick troubleshooting on 2026-05-02 after stricter OCR/source-evidence gate; only high-confidence passed rows with source-backed useful instructions were approved.
Searchable manual text plus skimmable details from the public FCC user manual.
The public manual includes useful button and port, status-light, setup, and power details.
Reset Button Management Port Data Port VDC Management Port 10/100 Mbps, secured Ethernet port for configuration.
Signal LEDs Signal 4 LED will light blue when on.
We recommend that you configure your paired AF‑11FX radios before site installation.
Follow the instructions for the source of power that you are using: Power over Ethernet or DC Power.
Reset Button Management Port Data Port VDC Management Port 10/100 Mbps, secured Ethernet port for configuration.
Signal LEDs Signal 4 LED will light blue when on.
LED State Status LINK Off RF Off Short Flash* Syncing Normal Flash* Beaconing Long Flash* Registering On Operational MIMO Off Radio configured in SISO mode On Radio configured in MIMO mode MGMT Off No Ethernet Link On...
We recommend that you configure your paired AF‑11FX radios before site installation.
Follow the instructions for the source of power that you are using: Power over Ethernet or DC Power.
