FCC ID 2AC7Z-EK058

Espressif EK058 module FCC filing (2AC7Z-EK058)

Name: Espressif EK058 FCC filing dataset
Creator: Espressif Systems (Shanghai) Co., Ltd.

Public FCC record for Espressif EK058 (2AC7Z-EK058), a digital transmission system device filed by Espressif Systems (Shanghai) Co., Ltd. Public exhibits include external photos, internal photos, a user manual, and RF exposure information. Radio evidence covers 2.4 GHz Wi-Fi / Bluetooth.

Networking 2AC7Z brand hub

ManufacturerEspressif Systems (Shanghai) Co., Ltd.

FCC ID2AC7Z-EK058

Device categoryNetworking

Authorization dateSep 29, 2022

Plain-English filing summary

What this FCC record tells you

EK058 is the device filed under FCC ID 2AC7Z-EK058 by Espressif Systems (Shanghai) Co., Ltd.

Public exhibits include internal and external photos, a user manual, RF exposure information, and wireless test reports.

The strongest extracted details are internal and external photos, wireless test measurements, and manual excerpts.

Those exhibits help verify what the device looks like, how its radios were tested, and setup or use details from the manual.

The listed radio coverage includes 2.4 GHz Wi-Fi / Bluetooth.

Manual excerpts cover power details and button controls.

Terms in this filing

FCC ID: A public identifier assigned to a wireless device authorization.
Grantee Code: The manufacturer/applicant portion of an FCC ID.
DTS: FCC equipment class for digital transmission systems.
Part 15C: FCC rules for many unlicensed intentional radiators.

Official FCC facts

FCC filing details

Raw application fields from the FCC record, shown separately from the plain-English summary.

Grantee code2AC7ZThe FCC-assigned applicant code at the start of the FCC ID.

Product code-EK058The filing-specific product code. It is not always the retail product name.

Application purposeOriginal EquipmentShows whether the FCC action was an original authorization, change, or related filing update.

FCC equipment classDSS - spread-spectrum wireless transmitterIn plain English, this covers a spread-spectrum wireless transmitter.

FCC rule partsPart 15C - low-power wireless rulesPart 15C is the FCC rule bucket used for many low-power Wi-Fi, Bluetooth, and similar transmitters.

Application IDQATQh38kJ30A15uNSXeSyg==The FCC tracking ID for this application batch.

Filing timeline

What changed in this filing

A quick read on what each public FCC application changed or confirmed, with source links attached.

Sep 29, 2022

Original Equipment

2 FCC applications

2 related FCC applications share this date and purpose, so they are grouped here instead of repeated as separate Original Equipment rows.

Applications: lipqSqf77sxQ1s8uujyG6A==, QATQh38kJ30A15uNSXeSyg==
Equipment classes: DTS - digital wireless transmitter; DSS - spread-spectrum wireless transmitter
FCC rules: Part 15C - low-power wireless rules
Bands: 2.4 GHz Wi-Fi / Bluetooth: 2 ranges
Public exhibits: user manual, external photos, internal photos, RF exposure, RF test report

SourcesFCC grant FCC exhibit list User manual

Wireless test details

Wireless details from FCC tests

This section summarizes what the FCC test documents say about the device's wireless connections and tested frequency ranges. RF exposure or SAR rows are compliance/safety context, not a speed or range claim.

This filing covers Wi-Fi-style wireless operation, including the shared frequency ranges shown below.

FCC equipment class	DTS - digital wireless transmitterThe FCC shorthand for the radio behavior reviewed in this filing.
FCC rule parts	Part 15C - low-power wireless rulesThe rule sections cited by the grant or test documents.
Frequency bands	2.4 GHz Wi-Fi / Bluetooth: 2 rangesThe radio ranges the FCC filing lists for the device.Source: FCC grant; 2 ranges grouped below
Frequency range	2412 - 2462 MHz \| 2402 - 2480 MHz \| 2402 - 2502 MHzSource: RF Exposure Info p. 5; Test Report p. 5
Maximum conducted output power	125 mWTransmit-power values come from lab testing and should not be read as a promised wireless range.Source: Test Report p. 4

Public photo exhibits

Public FCC photos

Product photos from public FCC exhibits, formatted for easier browsing. External photos show the enclosure and labels; internal photos show boards, antennas, and other compliance-relevant hardware.

External viewEspressif EK058 external FCC photo from External Photos p. 1Source: External Photos p. 1

External viewEspressif EK058 external FCC photo from External Photos p. 2Source: External Photos p. 2

External viewEspressif EK058 external FCC photo from External Photos p. 3Source: External Photos p. 3

External viewEspressif EK058 external FCC photo from External Photos p. 4Source: External Photos p. 4

External viewEspressif EK058 external FCC photo from External Photos p. 5Source: External Photos p. 5

External viewEspressif EK058 external FCC photo from External Photos p. 6Source: External Photos p. 6

Internal viewEspressif EK058 internal FCC photo from Internal Photos p. 1Source: Internal Photos p. 1

Internal viewEspressif EK058 internal FCC photo from Internal Photos p. 2Source: Internal Photos p. 2

User manual

Searchable manual text plus skimmable details from the public FCC user manual.

Official FCC source: Users Manual (6141695)20 pages1.5 MB public file

The public manual includes useful power, setup, and button and port details.

Manual at a glance

Get Started on EK058p. 5
Get Started on EK058p. 6
Get Started on EK058p. 9
Get Started on EK058p. 10

What power or charging details does the manual include?

Get Started on EK058 2.1 What You Need To develop applications for module you need:

1 x EK058 module
1 x Espressif RF testing board
1 x USB-to-Serial board
1 x Micro-USB cable
1 x PC running Linux In this us...

Source: Users Manual (6141695), page 5

How do I set up this device?

Source: Users Manual (6141695), page 6

What buttons or ports does the manual describe?

../../../components/esptool_py/esptool/esptool.py -p (PORT) -b 921600 write_flash --flash_mode dio --flash_size detect --flash_freq 40m 0x10000 build/hello-world.bin build 0x1000 build/bootloader/bootloader.bin 0x8000...

Source: Users Manual (6141695), page 9

Get Started on EK058

Get Started on EK058 2.1 What You Need To develop applications for module you need:

1 x EK058 module
1 x Espressif RF testing board
1 x USB-to-Serial board
1 x Micro-USB cable
1 x PC running Linux In this us...

Source: Users Manual (6141695), page 5

Get Started on EK058

Source: Users Manual (6141695), page 9
