Public FCC record for Espressif EK057 (2AC7Z-EK057), a digital transmission system device filed by Espressif Systems (Shanghai) Co., Ltd. Public exhibits include external photos, internal photos, a user manual, and RF exposure information. Radio evidence covers 2.4 GHz Wi-Fi / Bluetooth.

Networking2AC7Z brand hub
Espressif Systems (Shanghai) Co., Ltd.
2AC7Z-EK057
Networking
Dec 23, 2020
Plain-English filing summary

What this FCC record tells you

EK057 is the device filed under FCC ID 2AC7Z-EK057 by Espressif Systems (Shanghai) Co., Ltd.

Public exhibits include internal and external photos, a user manual, RF exposure information, and wireless test reports.

The strongest extracted details are internal photos and manual excerpts.

Those exhibits help verify what the device looks like, how its radios were tested, and setup or use details from the manual.

The listed radio coverage includes 2.4 GHz Wi-Fi / Bluetooth.

Manual excerpts cover button controls.
